Expert series Viscometer

5000 INR

Get a Price/Quote

Product Details:

Measurement Range 10 mPas to 100,000 mPas
Automation Grade Semi-Automatic
Model No Expert Series
Feature Auto Calibration, Data Logging, User-friendly Interface
Core Components Motor, Digital Controller, Spindle Set
Capacity 10 ml to 1000 ml
Power Source Electric
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Expert series Viscometer Price And Quantity

Price 5000 INR
Minimum Order Quantity 1 Piece

Expert series Viscometer Product Specifications

Dimension (L*W*H) 360 mm x 240 mm x 370 mm
Core Components Motor, Digital Controller, Spindle Set
Display Type Digital LCD display
Type Rotational Viscometer
Feature Auto Calibration, Data Logging, User-friendly Interface
Measurement Range 10 mPas to 100,000 mPas
Automation Grade Semi-Automatic
Model No Expert Series
Frequency 50/60 Hz
Equipment Materials Stainless Steel and ABS
Voltage 220V AC
Accuracy 1% of full scale
Usage Laboratory, Industrial applications
Temperature Range 0C to 100C
Power Source Electric
Capacity 10 ml to 1000 ml
Weight 7.5 kg

Expert series Viscometer Trade Information

Supply Ability 5-10 Piece piece Per Month
Delivery Time 6-8 Week

Product Description

Expert series

Add essential performances to determine viscosity and other rheological features to homogenious samples.

Features

Touch keyboard
Latest keyboarding technology,
comfortable and easy to handle (12 Keys)

Languages options
English / French / German / Catalan / Spanish / Italian / Japanese / Polish / Dutch / Portuguese

Program features
Time to torque
Time to stop
10 working memories
Customizable option (54 Speeds)
Programmable: Multistep/Ramp
Unit Converter (IS or CGS)

Viscosity readings
Absolute viscosity (cP or mPa·s)
Apparent Viscosity (cP or mPa·s)
Kinematic viscosity (cSt, mm2/sec)
(Density introduced by the user)

Auto-test
It checks the internal function in order to make the unit ready to use

Universal adapter
All accessories such as Brookfield (Optional)

Graphic display
Provides huge range of graphical options

10 working memories
Set up the unit and get it ready to be used every day choosing the memory you need

USB interface
Faster transfer data to the computer

Data displayed
Selected Speed
Selected Spindle
Viscosity readings (cP or mPa·s or cSt)
Percentage of Full Scale Range (%)
Sample Temperature (ºC or ºF)
Shear rate (with coaxial spindles) (s-1)
Shear Stress (with coaxial spindles) (N/m2)
Density (introduced by the user) (g/cm3)

Datalogger
(software included)
USB allows data transfer to a Excel format

Other features
Time to torque: target torque pre-setting device.
Time to stop: target time pre-setting device.
AUTO-TEST with sound and visual malfuction alarm
AUTO-ARANGE function

Spindles
AISI 316 stainless steel spindles, easily identified by number and letter when changed according to range of viscosity.

These are the standards our units follow:
BS: 6075, 5350
ISO: 2555, 1652
ASTM: 115, 789, 1076, 1084, 1286, 1417, 1439, 1638, 1824, 2196, 2336, 2364, 2393, 2556, 2669, 2849, 2983, 2994, 3232, 3236, 3716

Code	Model	Measuring Range (cP)	Speed (r.p.m)	Number of speeds
V300003	EXPERT L	*1 - 6.000.000	0.01 - 200	54
V300002	EXPERT R	100 - 40.000.000	0.01 - 200	54
V300001	EXPERT H	200 - 106.000.000	0.01 - 200	54

Precision Measurement Meets Versatile Application

The Expert Series Viscometer delivers reliable results for a wide range of samples, thanks to its broad viscosity measurement range and selectable spindle speeds. Suitable for research, production quality control, and development settings, the included L1-L4 spindles adapt to diverse fluid properties and sample volumes. Its digital LCD display provides intuitive readouts, streamlining daily laboratory workflows.

Built for Safety and Convenience

Safety and ease-of-use are at the core of this viscometers design. Users benefit from overload and over-temperature protection, minimizing risks during operation. The housing meets IP20 protection standards, and the unit can be operated in ambient conditions from 5C to 40C and humidity up to 85%. Both automatic and manual calibration ensure accurate measurements for consistent quality outcomes.

Flexible Data Management and Integration

With USB and RS232 interfaces, the Expert Series Viscometer supports seamless data output and integration with PC-based systems. The equipment comes with Windows-compatible software, allowing for streamlined data logging, management, and analysis. Whether for exporters, manufacturers, or research labs, this viscometer is designed to elevate productivity and reporting capabilities.

FAQs of Expert series Viscometer:

Q: How do I calibrate the Expert Series Viscometer?

A: The Expert Series Viscometer can be calibrated using either the automatic or manual method. For automatic calibration, follow the on-screen prompts provided via the digital LCD display. For manual calibration, refer to the user manual to perform step-by-step spindle calibration using certified calibration fluids. Regular calibration ensures measurement accuracy.

Q: What types of samples and industries can use this viscometer?

A: This viscometer is suitable for a wide range of samples with viscosities between 10 and 100,000 mPas, accommodating sample containers from 10 ml to 1000 ml. It is commonly used in laboratories and industrial environments, particularly in pharmaceuticals, chemicals, food & beverage, paint, and cosmetics sectors.

Q: When should I use the overload and over-temperature safety features?

A: The viscometer is equipped with built-in overload protection and over-temperature cutoff features, which automatically activate if the sample is too viscous or the operating temperature exceeds safe limits. These features safeguard both the equipment and user during testing, especially with unknown or new formulations.

Q: Where can I export or import this viscometer from in India?

A: The Expert Series Viscometer is available through various exporters, importers, manufacturers, suppliers, and traders based in India. For purchasing or distribution, contact your local scientific equipment supplier or reach out directly to the manufacturer for bulk or specialized orders.

Q: What is the process for data output and analysis?

A: Measurement data can be easily exported via USB or RS232 data interfaces to a connected PC. The viscometer includes Windows-compatible software, which facilitates data logging, analysis, and storage, allowing for thorough review and reporting of viscosity measurements.

Q: How does the digital display enhance usage and measurement accuracy?

A: The LCD digital display provides clear, real-time readouts of viscosity, spindle speed, and temperature, along with workflow prompts such as calibration or warnings. This minimizes user errors, facilitates swift decision-making, and ensures precise measurements every time.

Q: What are the main benefits of using this viscometer in my laboratory?

A: Key benefits include a wide measurement range, accurate readings, robust safety features, flexible data management, and simple calibration processes. Its modular spindle system, user-friendly interface, and reliable construction (stainless steel and ABS) make it an ideal choice for quality-driven laboratories and industrial applications.
