Alpha series Viscometer

5000 INR

Get a Price/Quote

Product Details:

Frequency 50 Hz
Accuracy 1% of full scale
Automation Grade Semi-Automatic
Core Components Motor, Spindle Set, Digital Display Unit
Feature LCD Display, Auto Stop, Programmable Speeds
Power Source 220V AC, 50 Hz
Capacity Multiple spindle options for variable sample volumes
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Alpha series Viscometer Price And Quantity

Minimum Order Quantity 1 Piece
Price 5000 INR

Alpha series Viscometer Product Specifications

Dimension (L*W*H) 400 x 350 x 500 mm
Weight 7 kg (approx.)
Voltage 220 V
Temperature Range 20C 100C
Measurement Range 10cP to 1,000,000cP
Capacity Multiple spindle options for variable sample volumes
Usage Laboratory, Industrial, Pharma, Paints, Oils, Chemical Analysis
Model No Alpha Series
Feature LCD Display, Auto Stop, Programmable Speeds
Equipment Materials Stainless Steel and ABS Body
Display Type Digital
Power Source 220V AC, 50 Hz
Type Brookfield Type Rotational Viscometer
Automation Grade Semi-Automatic
Accuracy 1% of full scale
Frequency 50 Hz
Core Components Motor, Spindle Set, Digital Display Unit

Alpha series Viscometer Trade Information

Supply Ability 5-10 Piece piece Per Month
Delivery Time 6-8 Week

Product Description

Alpha series

Alpha series rotational viscometers allow fast and accurate viscosity readings. They are low budget and easy to use.

Features

4 lines LCD display and keyboard controls

Languages options
English / French / German / Catalan / Spanish / Italian / Japanese / Polish / Dutch / Portuguese

Sound alarm
Under or over range

Universal adapter
All accessories such as Brookfield (Optional)

Friendly user auto range
Display of maximum measurable limits

Displayed info
Viscosity (cP or mPa·s) % Torque
Spindle
Speed

Auto-test
It checks the internal function in order to make the unit ready to use

Viscosity Reading
Relative and absolute viscosity.

Other features
Unit converter SI to CGS.
AUTO-TEST with sound and visual malfunction alarm.
AUTO-RANGE function.
User-enabled calibration.

Spindles
AISI 316 stainless steel spindles, easily identified by number and letter when changed according to range of viscosity.

These are the standards our units follow:
BS: 6075, 5350
ISO: 2555, 1652
ASTM: 115, 789, 1076, 1084, 1286, 1417, 1439, 1638, 1824, 2196, 2336, 2364, 2393, 2556, 2669, 2849, 2983, 2994, 3232, 3236, 3716

Code	Model	Measuring Range (cP)	Speed (r.p.m)	Number of speeds
V100003	ALPHA L	*1 - 2.000.000	0.3 - 100	18
V100002	ALPHA R	100 - 13.000.000	0.3 - 100	18
V100001	ALPHA H	200 - 106.000.000	0.3 - 100	18

Precision with Flexibility

The Alpha series Viscometer offers a broad measurement range of 10cP to 1,000,000cP, made possible by interchangeable spindles and programmable speeds. Its compatibility with various sample volumes makes it adaptable to changing laboratory requirements. The robust stainless steel and ABS construction ensures durability even in demanding industrial environments.

Seamless Data Handling and Connectivity

Equipped with a digital LCD display for real-time observations, this viscometer includes RS232 connectivity, allowing direct interfacing with computers for detailed digital recording and analysis. The automatic calculation feature streamlines workflow, ensuring consistent reporting and error minimization for research, development, and quality control teams.

Safety and Automation Features

Operator safety is prioritized via overload and overheating protection, reducing the risk of instrument damage. The spindle guard, auto-stop capability, and user-friendly controls simplify routine measurements, making operation efficient even for less experienced users.

FAQs of Alpha series Viscometer:

Q: How does the Alpha series Viscometer automatically measure viscosity?

A: The Alpha series Viscometer calculates viscosity in real-time using rotational speed, torque measurements, and spindle data. Its internal digital system provides automatic, precise readings on the LCD display, reducing manual effort and error.

Q: What are the main benefits of using standard spindles in this viscometer?

A: The supplied L1-L4 stainless steel spindles allow you to measure fluids with varying viscosities across a wide range (10cP to 1,000,000cP). These easily interchangeable spindles enable users to tailor measurements to specific sample types and volumes, ensuring flexibility in different applications.

Q: Where is this viscometer typically used?

A: The Alpha series Viscometer is widely employed in laboratories, industrial facilities, pharmaceutical research, paint formulation, oil analysis, and chemical testing. Its robust build and wide measurement range make it ideal for diverse analysis requirements.

Q: What process safeguards are included to protect the instrument?

A: The viscometer features built-in overload and overheating protection to prevent damage during extended use or accidental misuse. An included spindle guard further enhances mechanical safety, ensuring the instruments longevity.

Q: How is digital data captured and exported from the viscometer?

A: Digital viscosity readings are displayed in real time and can be recorded directly via the RS232 interface. This connectivity allows seamless transfer of measurement data to computers for further analysis, reporting, or long-term storage.

Q: When should the viscometer be operated for optimal performance?

A: For best results, operate the Alpha series Viscometer at ambient temperatures between 15C and 35C and humidity at or below 80%. This ensures accurate measurements and maintains the products operational integrity.

Q: What advantages does automatic viscosity calculation provide?

A: Automatic calculation streamlines the testing process, reducing operator workload and minimizing human error. This feature guarantees consistent, reliable results and enhances productivity, particularly in quality control or high-throughput environments.
